  2. Sikadur-30, 2-Part Epoxy Structural Adhesive, Interior & Exterior, Light Grey
Sikadur-30, 2-Part Epoxy Structural Adhesive, Interior & Exterior, Light Grey

Sikadur-30, 2-Part Epoxy Structural Adhesive, Interior & Exterior, Light Grey

Adhesives & Sealants
SIKA

Sika is a global leader in specialty chemicals for the construction and industrial sectors. The company develops and supplies innovative products and systems for bonding, sealing, damping, reinforcing, and protecting structures. With a strong focus on sustainability and performance, Sika serves a wide range of applications including concrete production, waterproofing, roofing, flooring, and structural strengthening.

Read more
https://www.polytrade.global/web/image/product.template/17568/image_1920?unique=b734672
You have already submitted a query for this product today.
  • Packing

This combination does not exist.

Contact Us
Preview TDS
Download TDS
General Specifications
Packaging 6 kg
Usage Bonding Structural Reinforcement (E.G. Carbodur® Plates, Steel Plates)
Usage Area Interior & Exterior
Color Light Grey
Chemical Base Epoxy resin
Storage Conditions +5 °C to +30 °C - Store in original, unopened, sealed, and undamaged packaging in dry conditions. Protect from direct sunlight.
Density 1.65 kg/L ±0.1 kg/L (components A+B mixed) (at +23 °C)
Service Temperature -40 >< +45
Application Time 30 - 60 min.
Curing Time 24 - 48 hours
Application Thickness N/A
Application Method Spatula or trowel
UV Resistant No
Moisture Resistant Yes
Mold Resistant No
Paintable No
Sealant No
Flexible No

Sikadur-30 is a thixotropic, structural 2-component adhesive, based on a combination of epoxy resins and special fillers, designed for use at normal temperatures between +8 °C and +35 °C.

  • Easy to mix and apply.
  • No primer needed.
  • High creep resistance under permanent load.
  • Very good adhesion to concrete, masonry, stonework, steel, cast iron, aluminium, timber and Sika CarboDur Plates.
  • Hardening is not affected by high humidity.
  • High strength adhesive.
  • Thixotropic: non-sag in vertical and overhead applications.
  • Hardens without shrinkage.
  • Different coloured components (for mixing control).
  • High initial and ultimate mechanical resistance.
  • High abrasion and shock resistance.
  • Impermeable to liquids and water vapour.
Usage
Adhesive for bonding structural reinforcement, particularly in structural strengthening works. Especially for the following uses:
  • Sika CarboDur Plates to concrete, brickwork and timber (for details see the Sika CarboDur Product Data Sheet, the “Method Statement for Sika CarboDur Externally Bonded Reinforcement” Ref: 850 41 05 and the “Method Statement for Sika CarboDur Near Surface Mounted Reinforcement” Ref: 850 41 07).
  • Steel plates to concrete (for details see the relevant Sika Technical information).
Advantages
Sikadur-30 has the following advantages:
  • Easy to mix and apply.
  • No primer needed.
  • High creep resistance under permanent load.
  • Very good adhesion to concrete, masonry, stonework, steel, cast iron, aluminium, timber and Sika CarboDur Plates.
  • Hardening is not affected by high humidity.
  • High strength adhesive.
  • Thixotropic: non-sag in vertical and overhead applications.
  • Hardens without shrinkage.
  • Different coloured components (for mixing control).
  • High initial and ultimate mechanical resistance.
  • High abrasion and shock resistance.
  • Impermeable to liquids and water vapour.
Packaging

6 kg (A+B)

Pre-batched unit

pallets of 480 kg (80 x 6 kg)
Colour

Component A: white

Component B: black

Components A+B mixed: light grey
Technical Information
Compressive Strength

Curing Time

Curing Temperature

+10 °C

+35 °C

12 hours

-

~85 N/mm2

1 day

~55 N/mm2

~90 N/mm2

3 days~70 N/mm2~90 N/mm2
7 days~75 N/mm2~90 N/mm2

Modulus of Elasticity in Compression

~9 600 N/mm2 (at 23 °C)

(ASTM D 695)

Tensile Strength

Curing Time

Curing Temperature

+15 °C

+35 °C

1 day

~20 N/mm2

~26 N/mm2

3 days

~23 N/mm2

~27 N/mm2

7 days~26 N/mm2~29 N/mm2



Shear Strength

Curing time

Curing Temperature

+15 °C

+23 °C

+35 °C

1 day

~4 N/mm2

-

~17 N/mm2

3 days

~15 N/mm2

-

~18 N/mm2

7 days~16 N/mm2

~18 N/mm2 (1)

~18 N/mm2

Concrete failure (~15 N/mm2)

(1) (DIN EN ISO 4624)

Tensile adhesion strength

Curing time

Substrate

Curing temperature
Adhesion strength

7 days

Concrete dry

+23 °C

> 4 N/mm2 *

7 days

Steel

+23 °C

>21 N/mm2

*100% concrete failure

Shrinkage

0.04 %

(FIP: Fédération Internationale de la Précontrainte)

Coefficient of Thermal Expansion

2.5 x 10−5 per °C (Temperature range: −20 °C to +40 °C)

(EN 1770)

Service Temperature

−40 °C to +45 °C (when cured at +23 °C)

Glass transition temperature

Curing time

Curing temperature

TG

30 days

+30 °C

+52 °C

Heat deflection temperature

Curing time

Curing temperature

HDT

3 hours

+80 °C

+53 °C

6 hours

+60 °C

+53 °C

7 days+35 °C+53 °C
7 days+10 °C+36 °C
Application Information
Mixing Ratio

Component A : Component B = 3 : 1 by weight or volume
When using bulk material the exact mixing ratio must be safeguarded by accurately weighing and dosing each component.
Layer Thickness

30 mm max.
Sag Flow

On vertical surfaces it is non-sag up to 3−5 mm thickness at 35 °C

(FIP: Fédération Internationale de la Précontrainte)
Squeezability

4’000 mm2 at +15 °C at 15 kg

(FIP: Fédération Internationale de la Précontrainte)
Product Temperature

Sikadur-30 must be applied at temperatures between +8 °C and +35 °C.
Ambient Air Temperature

+8 °C min. / +35 °C max.
Dew Point

Beware of condensation.
Substrate temperature during application must be at least 3 °C above dew point.
Substrate Temperature

+8 °C min. / +35 °C max.
Substrate Moisture Content

Max. 4 % pbw
When applied to matt damp concrete, brush the adhesive well into the substrate.
Pot Life

Temperature

Potlife

Open time

+8 °C

~120 minutes

~150 minutes

+20 °C

~90 minutes

~110 minutes

+35 °C~20 minutes~50 minutes

The pot-life begins when the resin and hardener are mixed. It is shorter at high temperatures and longer at low temperatures. The greater the quantity mixed, the shorter the pot-life. To obtain longer workability at high temperatures, the mixed adhesive may be divided into portions. Another method is to chill components A+B before mixing them (although not below +5 °C).
