Sarnafil T Scupper, Scurgeri laterale FPO

Name: Sarnafil T Scupper, Scurgeri laterale FPO
Brand: SIKA
SKU: PTG255.00130
Price: 382.00 RON
Availability: InStock

Categorie: Hidroizolare

SIKA

Sika is a global leader in specialty chemicals for the construction and industrial sectors. The company develops and supplies innovative products and systems for bonding, sealing, damping, reinforcing, and protecting structures. With a strong focus on sustainability and performance, Sika serves a wide range of applications including concrete production, waterproofing, roofing, flooring, and structural strengthening.

462,22 lei Taxe incluse
462.22 RON

Această combinație nu există.

Prefabricated FPO side drain

Sarnafil® T Scupper round is a prefabricated rigid polyolefin injection molded flat roof drain for use with Sika roofing membranes that can be heat welded to the drain.

Use

Parapet rainwater drainage for use with Sarnafil® and Sikaplan® membranes.

Advantages

Resistance to UV exposure
Membranes can be heat-welded directly to the base plate
Easy to apply
Hot air weldable
Recyclable

pack

Depending on the quantity ordered and the size of the product, they are packed on pallets or in cardboard boxes.

Color

beige

Typical technical data

Chemical base		Polypropylene (PP)
Validity period		5 years from the date of manufacture.
Storage conditions		The product must be stored in its original packaging, unopened, sealed and undamaged, in dry conditions and temperatures between + 5 °C (+ 41 °F) and + 30 °C (+ 86 °F). Always refer to the packaging. Handle with care.
Surface		sleek
size		Spigot Mainboard Debit Outer Ø length angle of inclination bend at 90° W × H/L Water depth 55 mm (2.17 in) / 75 mm (2.95 in) 40 mm (1.57 in) 450 mm (17.7 in) 0° 250 mm (9.84 in) × 150/100 mm (3.94 in) 0.50 l/s 1) / 0.75 l/s 1) 50 mm (1.97 in) 450 mm (17.7 in) 0° 250 mm (9.84 in) × 150/100 mm (3.94 in) 0.70 l/s 1) /1.00 l/s 1) 63 mm (2.48 in) 465 mm (18.3 in) 5° 320 mm (12.6 in) × 200/120 mm (4.72 in) 1.05 l/s / 1.40 l/s 75 mm (2.95 in) 465 mm (18.3 in) 5° 320 mm (12.6 in) × 200/120 mm (4.72 in) 1.25 l/s / 1.80 l/s 90 mm (3.54 in) 465 mm (18.3 in) 5° 320 mm (12.6 in)× 200/120 mm (4.72 in) 1.45 l/s / 2.35 l/s 1) Calculated values
Thickness		3.0 mm (0.118 in)
System structure		The following products should be considered for use depending on the roof design: - Sarnafil® TG 66 - Sarnafil® TS 77 - Sarnafil® TG 76

Application

Ambient air temperature

-20 °C (68 °F) min. / +60 °C (+140 °F) max.

Support temperature

-30 °C (86 °F) min. / +60 °C (+140 °F) max.

APPLICATION

Strictly follow the installation procedures as defined in the procedures, application manuals and work instructions, which must always be adapted to the actual site conditions. See the relevant section of the application manual: Sarnafil® T

The above design is only a sample of the options available, for reference purposes only. Our policy of continuous improvement may result in a change of specifications without notice. If any discrepencies might be between the data sheet values and standards, we reserve the rights to make technical changes. Our company will not be held responsible, as all or any of pictures, drawings, weights and dimensions details or other elements in this document are only indicative and must not be considered contractual. Contact our sales team for other specifications or custom made products.

Preview TDS

Download TDS

General Specifications
Ambalaj	Palet sau cutie
Lăţime	- mm
Lungime	- m
Greutate	- Kg
Utilizare	Evacuarea apelor pluviale prin parapet pentru utilizare cu membranele Sarnafil® și Sikaplan®
Baza chimică	Polipropilenă (PP)
Zona de utilizare	-
Culoare	Culoare bej
Condiții de depozitare	+5…+30 °C, loc uscat, ambalaj original
Densitate	-
Consum	-

Prefabricated FPO side drain

Sarnafil® T Scupper round is a prefabricated rigid polyolefin injection molded flat roof drain for use with Sika roofing membranes that can be heat welded to the drain.

Use

Parapet rainwater drainage for use with Sarnafil® and Sikaplan® membranes.

Advantages

Resistance to UV exposure
Membranes can be heat-welded directly to the base plate
Easy to apply
Hot air weldable
Recyclable

pack

Depending on the quantity ordered and the size of the product, they are packed on pallets or in cardboard boxes.

Color

beige

Typical technical data

Chemical base		Polypropylene (PP)
Validity period		5 years from the date of manufacture.
Storage conditions		The product must be stored in its original packaging, unopened, sealed and undamaged, in dry conditions and temperatures between + 5 °C (+ 41 °F) and + 30 °C (+ 86 °F). Always refer to the packaging. Handle with care.
Surface		sleek
size		Spigot Mainboard Debit Outer Ø length angle of inclination bend at 90° W × H/L Water depth 55 mm (2.17 in) / 75 mm (2.95 in) 40 mm (1.57 in) 450 mm (17.7 in) 0° 250 mm (9.84 in) × 150/100 mm (3.94 in) 0.50 l/s 1) / 0.75 l/s 1) 50 mm (1.97 in) 450 mm (17.7 in) 0° 250 mm (9.84 in) × 150/100 mm (3.94 in) 0.70 l/s 1) /1.00 l/s 1) 63 mm (2.48 in) 465 mm (18.3 in) 5° 320 mm (12.6 in) × 200/120 mm (4.72 in) 1.05 l/s / 1.40 l/s 75 mm (2.95 in) 465 mm (18.3 in) 5° 320 mm (12.6 in) × 200/120 mm (4.72 in) 1.25 l/s / 1.80 l/s 90 mm (3.54 in) 465 mm (18.3 in) 5° 320 mm (12.6 in)× 200/120 mm (4.72 in) 1.45 l/s / 2.35 l/s 1) Calculated values
Thickness		3.0 mm (0.118 in)
System structure		The following products should be considered for use depending on the roof design: - Sarnafil® TG 66 - Sarnafil® TS 77 - Sarnafil® TG 76

Application

Ambient air temperature

-20 °C (68 °F) min. / +60 °C (+140 °F) max.

Support temperature

-30 °C (86 °F) min. / +60 °C (+140 °F) max.

APPLICATION
