Sarnafil T Scupper, FPO Side Drains

Sarnafil T Scupper, FPO Side Drains

Waterproofing
SIKA

Sika is a global leader in specialty chemicals for the construction and industrial sectors. The company develops and supplies innovative products and systems for bonding, sealing, damping, reinforcing, and protecting structures. With a strong focus on sustainability and performance, Sika serves a wide range of applications including concrete production, waterproofing, roofing, flooring, and structural strengthening.

Read more
https://www.polytrade.global/web/image/product.template/40758/image_1920?unique=f2e1e15

462.22 lei Tax Included
462.22 RON

Not Available For Sale

You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
General Specifications
Packaging Pallet or carton
Width - mm
Length - m
Weight - Kg
Usage Parapet rainwater drainage for use with Sarnafil® and Sikaplan® membranes
Chemical Base Polypropylene (PP)
Usage Area -
Color Color beige
Storage Conditions +5…+30 °C, dry, original packaging
Density -
Consumption -

Prefabricated FPO side drain

Sarnafil® T Scupper round is a prefabricated rigid polyolefin injection molded flat roof drain for use with Sika roofing membranes that can be heat welded to the drain.

Use
  • Parapet rainwater drainage for use with Sarnafil® and Sikaplan® membranes.
Advantages
  • Resistance to UV exposure
  • Membranes can be heat-welded directly to the base plate
  • Easy to apply
  • Hot air weldable
  • Recyclable
pack

Depending on the quantity ordered and the size of the product, they are packed on pallets or in cardboard boxes.

Color
Colorbeige
Typical technical data
Chemical base

Polypropylene (PP)

Validity period

5 years from the date of manufacture.

Storage conditions

The product must be stored in its original packaging, unopened, sealed and undamaged, in dry conditions and temperatures between + 5 °C (+ 41 °F) and + 30 °C (+ 86 °F). Always refer to the packaging. Handle with care.

Surface

sleek

size

Spigot Mainboard Debit
Outer Ø length angle of inclination bend at 90° W × H/L Water depth 55 mm (2.17 in) / 75 mm (2.95 in)
40 mm (1.57 in) 450 mm (17.7 in) 0° 250 mm (9.84 in) × 150/100 mm (3.94 in) 0.50 l/s 1) / 0.75 l/s 1)
50 mm (1.97 in) 450 mm (17.7 in) 0° 250 mm (9.84 in) × 150/100 mm (3.94 in) 0.70 l/s 1) /1.00 l/s 1)
63 mm (2.48 in) 465 mm (18.3 in) 5° 320 mm (12.6 in) × 200/120 mm (4.72 in) 1.05 l/s / 1.40 l/s
75 mm (2.95 in) 465 mm (18.3 in) 5° 320 mm (12.6 in) × 200/120 mm (4.72 in) 1.25 l/s / 1.80 l/s
90 mm (3.54 in) 465 mm (18.3 in) 5° 320 mm (12.6 in)× 200/120 mm (4.72 in) 1.45 l/s / 2.35 l/s
1) Calculated values

Thickness

3.0 mm (0.118 in)

System structure

The following products should be considered for use depending on the roof design:
- Sarnafil® TG 66
- Sarnafil® TS 77
- Sarnafil® TG 76

Application
Ambient air temperature

-20 °C (68 °F) min. / +60 °C (+140 °F) max.

Support temperature

-30 °C (86 °F) min. / +60 °C (+140 °F) max.

APPLICATION

Strictly follow the installation procedures as defined in the procedures, application manuals and work instructions, which must always be adapted to the actual site conditions. See the relevant section of the application manual: Sarnafil® T
