CANADIAN SOLAR, CSI-SolBank-S-3328-2h-NA, Energy Storage System (ESS)

BESS
CANADIAN SOLAR

Canadian Solar is one of the most bankable companies in the solar and renewable energy industry, having been publicly listed on the NASDAQ since 2006. Canadian Solar has two business segments: CSI Solar and Recurrent Energy

Read more
https://www.polytrade.global/web/image/product.template/10152/image_1920?unique=ab4a244
You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
Identification
Brand CANADIAN SOLAR
Product Code CSI-SolBank-S-3328-2h-NA
General Specifications
Width 6058.0 mm
Height 2438.0 mm
Depth 2896.0 mm
Weight 30200.0 Kg
Operating Temperature -30 >< 55 °C
Max. Operating Altitude 2000.0 m
Relative Humidity ≤95 %
IP Rating IP 55
Battery Chemistry Lithium Iron Phosphate (LFP)
Max. Efficiency 93.0 %
Electrical Data
Rated AC Output Power N/A kVA
Rated DC Power 1545.0 kW
Storage Capacity 3095.0 kWh
DC Voltage (Nominal) 1324.8 V
DC Voltage Range 1159,2 ~ 1490,4 V
Max.Short Circuit Current 75.0 A
Protection
Protection <table class="table table-bordered"> <tbody> <tr> <td> <p style="text-align: justify;"> Thermal Management System: Liquid cooling/heating for battery system, air cooling for electrical components and humidity control. <br> Control Backup: 2-hrs UPS for control system including BMS, installed in the container. <br> Fire Detection and Alarm: Heat and smoke detection, alarm panel, bell and strobe with up to 24 hours UPS backup <br> Explosion Prevention: Gas detection with active ventilation. <br> Fire Suppression: Aerosol-based fire suppression system option available </p> <br> </td> </tr> </tbody> </table>
Communication
Communication Interface Ethernet, RS485, CAN
Communication Protocol Modbus TCP/IP, Modbus RTU, CAN 2.0

General Description & Application


SolBank 2.0 Energy Storage System

e-STORAGE is a leading company specializing in the design, manufacturing, and integration of battery energy storage systems for utility-scale applications. At the core of the e- STORAGE platform is SolBank, a self-manufactured, lithiumiron phosphate chemistry-based battery engineered for utilityscale applications. Through our innovative solutions, we aim to optimize grid operations, promote clean energy integration, and foster a more resilient and sustainable energy landscape.


Together, we are building a brighter, greener future for all.


e-STORAGE SolBank 2.0 is a modular, flexible, and costeffective battery energy storage product. Multiple units could be connected in parallel. SolBank 2.0 is designed to meet energy storage needs for today and for the future.


Key Features

  • Cost-effective and long service life
  • 314Ah LFP cell leads to high energy density
  • Active balancing BMS on pack and rack level, releases more energy and extends the life of the system
  • Liquid cooling technology with cell temperatures being controlled within the optimal operating range
  • Battery pack IP65 seal grade, avoid dust, moisture,and water condensation
  • Multi-stage thermal spread technology, effectively prevents battery heat spread and improves safety
  • Multi-level fire detection, monitor early thermal runaway of cells
  • All internal components including battery packs assembled in factory, reducing on-site installation costs
