SUNGROW, SBR160, Energy Storage System (ESS)

Category: BESS

SUNGROW

Sungrow is a leader in the research and development of solar inverters with the largest dedicated R&D team in the industry and a broad product portfolio offering PV inverter solutions and energy storage systems for utility-scale, commercial & industrial, and residential applications, as well as internationally recognized floating PV plant solutions, NEV driving solutions, EV charging solutions and renewable hydrogen production systems.

This combination does not exist.

General Description & Application

High Voltage LFP Battery

Sungrow SBR160 is a high voltage battery with lithium iron phosphate (LiFePO4) cells. These cells are free of cobalt and are considered the safest and most durable battery chemistry currently available. This makes these types of home batteries more environmentally friendly and future-proof.
The Sungrow SBR096 battery is modular in structure, compact in size and designed for direct use. It offers a flexible capacity ranging from 9.6 kWh to 102.4 kWh. Combined with Sungrow's three-phase hybrid inverter, this battery can operate in a range from 5 kW to 50 kW.

Key Features

HIGH-PERFORMANCE
FLEXIBILITY
SAFETY
EASY INSTALLATION

The above design is only a sample of the options available, for reference purposes only.

Our policy of continuous improvement may result in a change of specifications without notice. If any discrepencies might be between the data sheet values and standards, we reserve the rights to make technical changes. Our company will not be held responsible, as all or any of pictures, drawings, weights and dimensions details or other elements in this document are only indicative and must not be considered contractual.

Contact our sales team for other specifications or custom made products.

Preview TDS

Download TDS

Identification
Brand	SUNGROW
Product Code	SBR160
General Specifications
Width	625.0 mm
Height	805.0 mm
Depth	330.0 mm
Weight	180.0 Kg
Operating Temperature	-30 >< 50 °C
Max. Operating Altitude	2000.0 m
Relative Humidity	0 % ~ 95% %
IP Rating	IP 55
Battery Chemistry	LiFePO4 Prismatic Cell
Max. Efficiency	N/A %
Electrical Data
Rated AC Output Power	N/A kVA
Rated DC Power	5.76 kW
Storage Capacity	9.6 kWh
DC Voltage (Nominal)	192.0 V
DC Voltage Range	150 – 219 V
Max.Short Circuit Current	3.5 A
Protection
Protection	<table class="table table-bordered"> <tbody> <tr> <td> <p style="text-align: justify;"> Over / under voltage protection; Over current protection; Over / under temperature protection; DC breaker. </p> <br> </td> </tr> </tbody> </table>
Communication
Communication Interface	CAN
Communication Protocol	SOC indicator, status indicator
