ARELUX LDL1100-1500.63D, Linear DALI Dimmable LED Driver (1100-1500 mA)

ARELUX LDL1100-1500.63D, Linear DALI Dimmable LED Driver (1100-1500 mA)

Power Supplies
ARELUX

ARELUX offers professional LED control solutions including controllers, dimmers, and smart interfaces compatible with WiFi, RF, DMX, and DALI systems, suitable for residential and commercial lighting applications.

Read more
https://www.polytrade.global/web/image/product.template/33289/image_1920?unique=e933da6
You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
Identification
Brand ARELUX
Manufacturer Code LDL1100-1500.63D
General Specifications
Destination Indoor
Usage Commercial, Industrial
Working Temperature -20 >< +50 °C
Rated Input Voltage 220 - 240 V AC
Rated Output Voltage 25 - 42 V
Rated Current 1100-1500 mA
IP Rating IP20
Length mm
Height mm
Width mm
Rated Output Power 63 W

General Description & Application

Linear dimmable DALI driver. Output current can be selected from 1100 mA to 1500 mA via a DIP switch, 50mA for every step. Equipped with DALI and push dimming functions. The DALI dimming function and the push dimming function cannot be used at the same time otherwise the DALI dimmer will be damaged.

Product type: Driver

Housing/structure: Housing of grey iron sheet.

Electrical gear: Self-locking terminal blocks, 0,75 to 1,5 mm² diameter of wires for input and 0,5 to 1 mm² diameter for output. DIP switch 4P for the selection of the output current. Auto-recovery short circuit protection. Open circuit protection (<55V DC).
