ARELUX LD700.28, 700 mA Constant Current LED Driver (Compact)

ARELUX LD700.28, 700 mA Constant Current LED Driver (Compact)

Power Supplies
ARELUX

ARELUX offers professional LED control solutions including controllers, dimmers, and smart interfaces compatible with WiFi, RF, DMX, and DALI systems, suitable for residential and commercial lighting applications.

Read more
https://www.polytrade.global/web/image/product.template/33304/image_1920?unique=e933da6
You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
Identification
Brand ARELUX
Manufacturer Code LD700.28
General Specifications
Destination Indoor
Usage Commercial, Industrial
Working Temperature -20 >< +50 °C
Rated Input Voltage 220 - 240 V AC
Rated Output Voltage 33 - 40 V DC
Rated Current 700 mA
IP Rating IP20
Length mm
Height mm
Width mm
Rated Output Power 28 W

General Description & Application

Constant current driver (700 mA), compact, for LED circuits.

Product type: Driver

Housing/structure: White polycarbonate case.

Electrical gear: Self-locking terminal blocks, 0,75 to 1 mm² diameter of wires for input and 0,5 to 1 mm² diameter for the load connection. Auto-recovery short circuit protection. Open circuit protection (<55V DC).
