GEWISS GWD9151, Msx 125, Moulded Case Circuit Breakers, Thermal Adjustable, Magnetic Adjustable, 65Ka 3P 20A 690V

GEWISS GWD9151, Msx 125, Moulded Case Circuit Breakers, Thermal Adjustable, Magnetic Adjustable, 65Ka 3P 20A 690V

Circuit Breakers
GEWISS

Founded in 1970 on the revolutionary innovation of using technopolymer in electrical engineering, today GEWISS is the most important company in the electrotechnical sector with Italian capital.

Read more
https://www.polytrade.global/web/image/product.template/11435/image_1920?unique=ab4a244
You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
Identification
Brand GEWISS
Manufacturer Code GWD9151
Circuit Breaker Type MCCB
Product Family MSX-Moulded case circuit breaker for power distribution
General Specifications
Number of poles 3P
Rated current 20.0 A
Auxiliaries compatibility N/A
ReStart compatibility N/A
No. modules N/A
Rated residual operating current N/A mA
Rated frequency 50 / 60 Hz
Insulation voltage (Ui) 800.0 V
Rated impulse withstand voltage (Uimp) 8.0 kV
Overvoltage category IV
Operating Temperature -5 >< +65 °C
Stocking temperature -20 >< +65 °C
Electrical endurance N/A
Mechanical endurance N/A
Curve N/A
Energy limiting class N/A
Standards IEC/EN 60947-2

General Description & Application


The moulded case circuit breakers MSX range is made up of circuit breakers with thermo-magnetic release, circuit breakers with thermo-magnetic release and Overcurrent Protection, circuit breakers with electronic release and switch disconnectors.
