  2. JA SOLAR, JAM72D10-MB-415W, Standard Bifacial Monocrystalline MBB PERCIUM Half-Cell 415Wp Solar Panel

JA SOLAR, JAM72D10-MB-415W, Standard Bifacial Monocrystalline MBB PERCIUM Half-Cell 415Wp Solar Panel

PV Panels
JA SOLAR

As a photovoltaic power generation solution platform, JA Solar Technology Co., Ltd. continues to advance its "One Body, Two Wings" strategy. The "One Body" refers to our main industry chain integrating silicon wafers, cells, and modules, while the "Two Wings" refer to our PV auxiliary materials and equipment industry and PV+ application scenario solutions.

Read more
https://www.polytrade.global/web/image/product.template/5608/image_1920?unique=ab4a244
You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
Identification
Brand JA SOLAR
Product Code JAM72D10-MB-415W
Design & Mechanical Specification
Panel Type Bifacial
Panel Surface Standard
Panel Weight 25.0 Kg
Panel Length 2037.0 mm
Panel Width 1005.0 mm
Panel Thickness 30.0 mm
Cell Material Monocrystalline
Cell Type MBB PERCIUM Half-Cell
No. of Cells 144.0
Cell Dimension N/A
Glass Type Double
Encapsulation Type EVA
Junction Box IP Rate 68.0
Frame Type Anodized aluminum alloy
Connector Type MC4-EVO2/ QC 4.10-35
Wind Load 2400.0 Pa
Mechanical Load 5400.0 Pa
Operating Temperature -40 >< +85 °C
Electrical Specifications (*STC)
Nominal Max Power - Pmax 415.0 Wp
Maximum Operating Voltage - Vmpp 42.8 V
Maximum Operation Current - Impp 9.7 A
Open Circuit Voltage - Voc 50.35 V
Short Circuit Current - Isc 10.32 A
Module Efficiency - η 20.3 %
Power Tolerance (+)5% Wp
Maximum System Voltage 1500.0 V
Maximum Series Fuse Rating 20.0 A
Warranty
Products Warranty 12.0 yrs
Performance Warranty 30.0 yrs

General Description & Application

Solar panels are engineered for maximum efficiency, capturing sunlight and converting it into electricity with remarkable precision. Solar panels incorporate the latest advancements, ensuring you benefit from the most efficient and reliable solar solutions available on the market.
From extreme weather conditions to daily wear and tear, solar panels are designed to provide long-lasting, reliable performance, ensuring a sound investment in your energy future.
With solar panels, you're actively contributing to the reduction of greenhouse gas emissions and promoting a cleaner, healthier planet for generations to come.

Standards

Solar panels are engineered and testing according to below standards, as the case may be:
Low Voltage EU Directive 2014/35/EU
IEC 60068-2-68:1994
IEC 61215-1:2016
IEC 61215-1-1:2016
IEC 61215-2:2016
IEC 61730-1:2016
IEC 61730-2:2016
EN 61215-1:2016
EN 61215-1-1:2016
EN 61215-2:2017
EN 61730-1:2018
EN 61730-2:2018
IEC 61701:2011
EN 61701:2012
IEC 62716:2013
EN 62716:2013
IEC 62804-1:2015 / 2 PFG 2387/01.18
IEC 60068-2-68:1994
