  2. Solis Mini-1500-4G, 1.5kW, Single Phase Inverter

Solis Mini-1500-4G, 1.5kW, Single Phase Inverter

Inverters
SOLIS

Established in 2005, Ginlong (Solis) is recognized as the world’s third-largest PV inverter manufacturer. As a global provider of solar and energy storage solutions for residential, commercial, and utility-scale customers, the company delivers value throughout the solar supply chain. Operating under the Solis brand, its solar inverter product line utilizes innovative string technology, ensuring top-tier reliability validated by rigorous international certifications.

Read more
https://www.polytrade.global/web/image/product.template/16172/image_1920?unique=ab4a244
You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
Identifications
Brand Solis
Product Code Solis-mini-1500-4G
Type Single Phase
General Specifications
Width 373.0 mm
Height 310.0 mm
Depth 160.0 mm
Weight 7.4 Kg
Min. Operating Temperature -25.0 °C
Max. Operating Temperature 60.0 °C
Max. Operating Altitude 4000.0 m
Relative Humidity 0-100 %
Topology Transformerless
IP Rating IP66
Max. Efficiency 97.2 %
Input
Max. Input Voltage 600.0 V
Rated Input Voltage 200.0 V
Max. Input Current 11.0 A
Max.Short Circuit Current 17.2 A
Start Voltage 60.0 V
No. of MPPTS 1.0
Max. number of inputs 1.0
MPPT Operating Voltage Range 50 - 500 V
Output
Rated Output Power 1500.0 W
Max. AC Apparent Power 1700.0 VA
Max. Output Power 1700.0 W
Rated AC Output Voltage 220/230 VA
Rated Grid Frequency 50/60 Hz
Max. Output Current 8.1 A
Total Harmonic Distortion <3 %
Power Factor >0,99
Protection
Anti-islanding Protection Yes
AC Short Circuit Protection Yes
AC Overcurrent Protection Yes
Insulation Detection Yes
AC Surge Arrester Yes
DC Surge Arrester Yes
DC Reverse Connection Yes
Communication
WiFi Optional: Wi-Fi, GPRS
RS485 Yes
Monitoring BUS (MBUS) N/A
Display LCD
USB No

General Description & Application

Solis-Mini(700-3600)-4G

Key Features:

  • Solis Mini Series Inverter

  • Solis-Mini4G Single-phase series string inverter are green power leader in affordable small residential and commercial rooftops, adopt full digital control technology, advanced topological structure and accurate MPPT algorithm, whose efficiency higher than the industry's leading conversion is up to 97.5% at the maximum.Meanwhile adopt multiple protection functions,ultra-high switching frequency technology.
