Fire Alarm Cable JY(ST)Y 4x2 CL-1 RM 300V

Fire Alarm Cable JY(ST)Y 4x2 CL-1 RM 300V

JY(ST)Y
POWERVINE

Powervine is a trusted brand in the energy industry, specializing in the production of top-quality energy cables and equipment. Our products are designed to provide safe and efficient power transmission, with a focus on sustainability and environmental responsibility. We use only the highest-quality materials and the latest manufacturing techniques to ensure that our products meet the strictest industry standards for safety, reliability, and performance. Whether you're looking for cables and equipment for a renewable energy project or traditional power transmission, Powervine has the products and expertise you need to achieve your goals.

Read more
https://www.polytrade.global/web/image/product.template/3510/image_1920?unique=ab4a244
You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
Specifications
Cable Type Multi core
Cable Overall Diameter 8 mm
Cable Weight 90 kg/km
Conductor Material Copper
Number of Conductors 4
Conductor Cross-Section 2 mm²
Conductor Weight 41 kg/km
Conductor Class CL-1
Conductor Type RM
Insulation Material PVC
Outersheath Material PVC
Rated Voltage (Uo/U) 0.3 kV
Max. Permissible Operating Temperature -30 >< +70 °C
Working Temperature -30 >< +70 °C
Short Circuit Temperature N/A °C
Minimum Bending Radius (Installing) 10xD
Minimum Bending Radius (Operating) 8xD
Packing Rolls
Delivery Lengths To be confirmed by offer
Delivery Length Tolerance ±5%

General Description & Application

JY(ST)Y cables are used indoor for fire alarm systems that transmits the signal and data between control panels , detectors , buttons and area control modules.

Standards

EN 60228
EN 50290-2-21
EN 50290-2-22
EN 60332-1-2
TS13767

Construction

Conductor: Class 1 copper
Insulation: PVC
Sheath: PVC
