Sikafloor Earthing Kit

Sikafloor Earthing Kit

Flooring
SIKA

Sika is a global leader in specialty chemicals for the construction and industrial sectors. The company develops and supplies innovative products and systems for bonding, sealing, damping, reinforcing, and protecting structures. With a strong focus on sustainability and performance, Sika serves a wide range of applications including concrete production, waterproofing, roofing, flooring, and structural strengthening.

Read more
https://www.polytrade.global/web/image/product.template/40669/image_1920?unique=c88dc28

2,845.92 lei Tax Included
2845.92 RON

Not Available For Sale

You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
General Specifications
Chemical Base -
Consumption 1 earthing point is able to conduct over a floor area of ~200–300 m²
Resistance to impact -
Appearance -
Ambient Air Temperature -
Color -
Application Thickness -

Earthing Kit For Electrostatic Conductive Floors

Sikafloor® Conductive Set is an earthing kit to connect electrostatic conductive floor systems to ground. Suitable for use in hot and tropical climatic conditions.

Usage
  • Ground connection point for decorative and protective electrostatic conductive flooring systems used in automotive, electronics and pharmaceutical manufacturing, storage facilities and warehouses.
Advantages
  • Good mechanical resistance
  • Cost effective
  • Easy to apply
  • Secure connection
Packaging

10 earthing points supplied in a plastic box.

Refer to current price list for packaging variations.

Typical Product Data
Shelf life

5 years from date of production

Storage conditions

The product must be stored in original, unopened and undamaged sealed packaging in dry conditions at temperatures between +5 °C (+41 °F) and +30 °C (+86 °F). Always refer to packaging.

Application
Consumption

1 earthing point is able to conduct over a floor area of ~200–300 m².

Longest distance of each earthing point to the next earthing point is 20 m (65.6 ft) maximum. For longer distances, additional earthing points must be provided.

APPLICATION

Reference must be made to further documentation where applicable, such as relevant method statement, application manual and installation or working instructions.

  1. When primer has cured, drill a hole: diameter 8 mm (0.315 in), depth >50 mm (1.97 in).
  2. Remove all dust, loose and friable material around drilled hole and insert a size 8 plastic plug. The plug must be flush with the floor surface.
  3. Screw the threaded dowel rod with a hexagonal socket into the plastic plug with an Allen key. Dowel rod must extend 16 mm (0.63 in) above the floor.
  4. Fully bond the copper strips (2 × 10 mm (0.394 in)) on both sides of the hole.
  5. Place the large (D=60 mm (2.36 in)) washer followed by the smaller (D=30 mm (1.18 in)) washer over the threaded dowel rod and secure with the nut (M6) so the washers are pressed onto the copper strips ensuring good contact.
  6. Push the transparent plastic hose over the threaded dowel rod so the hose fits tightly.
  7. Apply the selected Sikafloor® conductive primer and conductive wearing finish ensuring all washers and copper tape are completely covered.
  8. After curing of the Sikafloor® products, remove the transparent plastic hose.
  9. Clean the head of the threaded dowel rod.
  10. Fix the brass eyelet using the self‐locking nut (M6) onto the threaded dowel rod.
  11. Connect the grounding cable with the brass eyelet.
