Sikacrete-301 Premium, Durable spray concrete large-area structural repairs, Interior & Exterior, Black, 25 kg

Category: Cement & Mortar

SIKA

Sika is a global leader in specialty chemicals for the construction and industrial sectors. The company develops and supplies innovative products and systems for bonding, sealing, damping, reinforcing, and protecting structures. With a strong focus on sustainability and performance, Sika serves a wide range of applications including concrete production, waterproofing, roofing, flooring, and structural strengthening.

This combination does not exist.

High Performance Class R4 Dry Sprayed Micro-Concrete for Large Volume Repairs

Sikacrete-301 Premium (formerly SikaCem-133 S Gunite) is a cement based, polymer modified, one-component repair micro-concrete containing silica fume and high range water-reducing agents, meeting the requirements of EN 1504-3 Class R4. Formulated for machine applications using the dry process without set accelerators, repairs may be profiled and trowel finished easily where necessary.

One component, ready to use.
Non-silica aggregates, so no risk of alkali silica reactivity (ASR).
Easy and quick to set up.
Low rebound losses and dust formation during the spraying process.
High build - layer thicknesses in one application overhead up to 150mm are possible without any additional mesh reinforcement.
Rapid strength gain without set accelerators.
Very low shrinkage.
Can be finished easily to a high standard.
Overcoatable with Sika reprofiling / levelling / smoothing mortars and coatings.
EN 1504-3 Class R4.
Low resistivity - can be used with cathodic protection systems.
Suitable for use in contact with potable water.

Usage

Large volume repairs.
Highways works.
Bridges (columns, piers, sofits, beams, parapets, abutments, etc.).
Marine structures (quays, piers, jetties, sea walls, docks, dry docks, marinas, offshore platforms, cofferdams, caissons, etc.).
Water facilities (reservoirs, dams, tanks, buildings, treatment works, etc.).
Tunnels.
Faςades.
For exterior and interior use.
In place of Class R1, R2 and R3 mortars.
Low resistivity - can be used with cathodic protection systems.

Advantages

One component, ready to use.
Non-silica aggregates, so no risk of alkali silica reactivity (ASR).
Easy and quick to set up.
Low rebound losses and dust formation during the spraying process.
High build - layer thicknesses in one application overhead up to 150mm are possible without any additional mesh reinforcement.
Rapid strength gain without set accelerators.
Very low shrinkage.
Can be finished easily to a high standard.
Overcoatable with Sika reprofiling / levelling / smoothing mortars and coatings.
EN 1504-3 Class R4.
Low resistivity - can be used with cathodic protection systems.
Suitable for use in contact with potable water.

Packaging

25 kg bag

Technical Information

Compressive Strength

1 Day	~15 MPa
7 Days	~35 MPa
14 Days	~50 MPa
28 Days	~60 MPa

Modulus of Elasticity in Compression

~23 GPa

(EN 13412)

Flexural Strength

28 Days

~10 MPa

Tensile Strength

~2.5 MPa

(EN 1542)

Shear Strength

µ = 60,000

Coefficient of Thermal Expansion

8 x 10^-6 m/m ^oC

Electrical Resistivity

~14.4 kΩcm

Capillary Absorption

0.14 kg.m^-2.h^-0.5

(EN 13057)

Diffusion Resistance to Water Vapour

µ = 1,000

Chloride Ion Diffusion Resistance

600 – 700 x 10^-15 m²/s

Freeze Thaw De-Icing Salt Resistance

106% - good resistance with no visible change after 400 cycles.

NOTE: Determined in accordance with SN 640461 - Resistivity factor WFT-L.

Application Information

Fresh mortar density

~2.2 kg/l

Layer Thickness

10 mm minimum / 150 mm maximum

Ambient Air Temperature

+3°C minimum / +30°C maximum

Substrate Temperature

+3°C minimum / +30°C maximum

The above design is only a sample of the options available, for reference purposes only. Our policy of continuous improvement may result in a change of specifications without notice. If any discrepencies might be between the data sheet values and standards, we reserve the rights to make technical changes. Our company will not be held responsible, as all or any of pictures, drawings, weights and dimensions details or other elements in this document are only indicative and must not be considered contractual. Contact our sales team for other specifications or custom made products.

Contact our sales team for other specifications or custom made products.

Preview TDS

Download TDS

General Specifications
Packaging	25 kg
Usage	Large volume repairs for highways, bridges, marine structures, water facilities, tunnels, facades
Usage Area	Interior & Exterior
Color	Black
Chemical Base	Portland cement, polymers, selected aggregates, silica fume and additives.
Storage Conditions	Store properly in original unopened, sealed and undamaged packaging in dry and cool conditions.
Density	2300 kg/m³
Application Thickness	10 mm >< 150 mm
Ambient Air Temperature	+3°C >< +30°C
Substrate Temperature	+3°C >< +30°C
Working time	N/A
Waiting Time	N/A
Consumption	2.2 kg/m²/mm
