Sarnafil T Metal Sheet, FPO Membrane Cased Sheet

Sarnafil T Metal Sheet, FPO Membrane Cased Sheet

Waterproofing
SIKA

Sika is a global leader in specialty chemicals for the construction and industrial sectors. The company develops and supplies innovative products and systems for bonding, sealing, damping, reinforcing, and protecting structures. With a strong focus on sustainability and performance, Sika serves a wide range of applications including concrete production, waterproofing, roofing, flooring, and structural strengthening.

Read more
https://www.polytrade.global/web/image/product.template/40756/image_1920?unique=f2e1e15

1,592.36 lei Tax Included
1592.36 RON

Not Available For Sale

You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
General Specifications
Packaging Sheets 2×1 m / 3×1 m; coil 30×1 m
Width - mm
Length - m
Weight - Kg
Usage Profiles for perimeter fastenings; Sarnafil® T (FPO) systems
Chemical Base FPO top layer + galvanised steel (DX51D Z275) with epoxy coating
Usage Area -
Color Total 1.70 mm (FPO 1.10 + steel 0.60); 4 colours
Storage Conditions +5…+30 °C, dry, original packaging
Density -
Consumption -

Metal sheets and coils laminated with Sarnafil® T roof waterproofing membrane

Sarnafil® T Metal Sheet/coil is a galvanised steel sheet or coil, laminated with Sarnafil® T flexible polyolefin (FPO) roof waterproofing membrane.

Usage

Production of profiles for perimeter fastenings and junctions.

  • Sarnafil® T (FPO) roof waterproofing membrane systems
Advantages
  • Resistant to UV exposure
  • Can be cut and shaped either on site or in metal workshop
  • Sarnafil® T lamination is hot air weldable
Packaging

Sarnafil® T Metal Sheet

packing unit100 sheets per pallet 70 sheets per pallet
length2,00 m 3,00 m (9.84 ft)
width1,00 m (3.28 ft) 1,00 m (3.28 ft)
weight5,70 kg/m 2 (+/-8 %) 5,70 kg/m 2 (+/-8 %)
weight per sheet11,40 kg (25.1 lb) (+/-8 %) 17,10 kg (37.7 lb) (+/-8 %)

Sarnafil® T Metal Coil

packing unit4 coils per pallet
length30,00 m (98.4 ft)
width1,00 m (3.28 ft)
weight5,70 kg/m 2 (+/-8 %)
weight per sheet171 kg (377 lb) (+/-8 %)

Refer to current price list for packaging variations

Colour
Surface:smooth

Thickness:

Sarnafil® T lamination:1,10 mm (0.0433 in) (-0,055 mm (0.0022 in) / +0,110 mm (+0.0043 in))
Galvanised metal:0,60 mm (0.0236 in) (+/-0,060 mm (0.0024 in))
Total thickness:1,70 mm (0.0669 in) (-0,115 / +0,170 mm (+0.0067 in))

Colour:

Top surface:beige window grey (nearest RAL 7040) traffic white (nearest RAL 9016) anthracite grey (nearest RAL 7016) light grey (nearest RAL 7035)
other colours on request
Bottom surface:Metal: cut (Epoxy-protection coated)
Typical Product Data
Chemical Base

Top layer: Flexible polyolefins (FPO) unreinforced
Bottom layer: Galvanised steel (quality DX51D Z275) with epoxy coating protection

Shelf Life

5 years from date of production

Storage Conditions

The product must be stored in original, unopened and undamaged sealed packaging in dry conditions at temperatures between +5 °C (+41 °F) and +30 °C (+86 °F). Do not stack pallets of Metal sheets or coils on top of each other, or under pallets of any other materials during transport or storage. Always refer to packaging.

System Structure

The following products must be considered for use depending on roof design:
- Sarnaplast®-2235
- Primer T 501
- S-Sealing Tape (10 mm (0.394 in) × 10 mm (0.394 in) × 25 m (82 ft))
- Sarnafil® TG 66 types
- Sarnafil® TG 76 types
- Sarnafil® TS 77 types
- Sarnafil® T 66-15 D

Application
Ambient Air Temperature

-20 °C (68 °F) min. / +60 °C (+140 °F) max.

Substrate Temperature

-30 °C (86 °F) min. / +60 °C (+140 °F) max.
