Sarnafil® T Walkway Pad, Grey

Sarnafil® T Walkway Pad, Grey

Waterproofing
SIKA

Sika is a global leader in specialty chemicals for the construction and industrial sectors. The company develops and supplies innovative products and systems for bonding, sealing, damping, reinforcing, and protecting structures. With a strong focus on sustainability and performance, Sika serves a wide range of applications including concrete production, waterproofing, roofing, flooring, and structural strengthening.

Read more
https://www.polytrade.global/web/image/product.template/40761/image_1920?unique=c88dc28

704.22 lei Tax Included
704.22 RON

Not Available For Sale

You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
General Specifications
Packaging 15 pcs/box
Width 600 mm (+3 mm / -3 mm) without the welding edges mm
Length 600mm (+3mm / -3mm) m
Weight 2.1 kg/pad Kg
Usage Anti-slip walkway pads for Sarnafil® T roofs
Chemical Base Flexible polyolefin (FPO) based on polypropylene (PP)
Usage Area -
Color Surface Ribs of different heights oriented in a zigzag pattern (Chevron) Color Dark gray
Storage Conditions Sarnafil® T Walkway Pad must be stored in dry conditions
Density -
Consumption -

Forests for traffic from FPO

Sarnafil® T Walkway Pads are manufactured from high quality flexible polyolefin (FPO) obtained by injection molding process.

Use

Sarnafil® T Walkway Pads are used against slipping on the membrane surface in case of access or maintenance work on roofs made with Sarnafil® T membranes.

Advantages
  • Permanent UV resistance
  • Non-slip surface
  • It is welded with hot air, without an open flame
  • Drainage of rainwater under the Sarnafil® T Walkway Pad is ensured by a network of cast channels
  • recycle
pack

Cardboard box with 15 sticks

Color
SurfaceRibs of different heights oriented in a zigzag pattern (Chevron)
ColorDark grey
Typical technical data
APPROVALS / CERTIFICATIONS

- Reaction to fire in accordance with the EN 13501-1 standard, class E
- Slip resistance to BS 7976-2, PTV >50
- Slip resistance in accordance with DIN 51130, R 10
- Sliding of a volume in accordance with the standard DIN 51130, V 10
- EN ISO 9001/14001 quality management system

Chemical base

Flexible polyolefin (FPO) based on polypropylene (PP)

Validity period

Sarnafil® T Walkway Pads do not expire if stored correctly.

Storage conditions

Sarnafil® T Walkway Pad must be stored in dry conditions.

Length

600mm (23.6 in) (+3mm (+0.118 in) / -3mm (0.118 in))

Width

600 mm (23.6 in) (+3 mm (+0.118 in) / -3 mm (0.118 in)) without the welding edges

Thickness

9.3 mm (0.366 in) (+1 mm (+0.0394 in) / -1 mm (0.0394 in)) including 3/5 mm (0.197 in) height of zigzag ribs

Mass per unit area

2.1 kg/pad

System structure

Compatible products Sarnafil® TG 66 Sarnafil® TS 77 Sarnafil® TG 76

Reaction to fire

Class E EN 13501-1

Application
Ambient air temperature

-20 °C (68 °F) min. / +60 °C (+140 °F) max.

Support temperature

-30 °C (86 °F) min. / +60 °C (+140 °F) max.

APPLICATION

Installation work must only be carried out by Sika authorized roofing membrane applicators.

Application of auxiliary products, e.g. contact adhesives / cleaning agents, is limited to temperatures above +5 °C (+41 °F). Please consult the technical data sheets of the respective products.

For application at an ambient temperature below +5 °C (+41 °F), mandatory measures may be required due to safety requirements according to national regulations.
