Sarnafil® TG 66-18, FPO Green Roof Membrane

Sarnafil® TG 66-18, FPO Green Roof Membrane

Waterproofing
SIKA

Sika is a global leader in specialty chemicals for the construction and industrial sectors. The company develops and supplies innovative products and systems for bonding, sealing, damping, reinforcing, and protecting structures. With a strong focus on sustainability and performance, Sika serves a wide range of applications including concrete production, waterproofing, roofing, flooring, and structural strengthening.

Read more
https://www.polytrade.global/web/image/product.template/40764/image_1920?unique=c88dc28

8,184.44 lei Tax Included
8184.44 RON

Not Available For Sale

You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
General Specifications
Packaging Roll
Width 2 m (-0.5 % / +1 %) mm
Length 15 m (-0 % / +5 %) m
Weight 1.8 kg/m² (- 5 % / + 10 %) Kg
Usage Membrane for ballasted roofs: green, utility, inverted
Chemical Base -
Usage Area -
Color Surface Matt Colours Top surface Beige Grey (nearest RAL 7040) Bottom surface Black
Storage Conditions Rolls: +5…+30 °C, horizontal on pallet, away from sun/rain/snow
Density -
Consumption -

Polymeric membrane for ballasted roof waterproofing

Sarnafil® TG 66-18 (thickness 1.8 mm (0.0709 in)) is a multi-layer, synthetic roof waterproofing sheet based on premium-quality flexible polyolefins (FPO), with inlay of glass non-woven according to EN 13956. Sarnafil® TG 66-18 is a hot air weldable, UV-resistant roof membrane. Suitable for use in hot and tropical climatic conditions.

Usage

Roof waterproofing membrane for roofs with ballast (example gravel, concrete slabs, green roof) and / or exposed flat roofs:

  • Loosely laid and ballasted roofs
  • Green roofs
  • Utility roofs
  • Inverted roofs

Roof waterproofing membrane for exposed roof junction zones:

  • Roof waterproofing for junctions and flashings, example wall and parapet junctions, roof lights, etc., which are permanently exposed in installations of Sarnafil® TG 66-18 roof waterproofing systems with ballast.
  • Roof waterproofing for junctions and flashings in installations of all types of Sarnafil® TS 77 and TG 76 Felt exposed roof waterproofing systems.
Advantages
  • Proven performance over decades
  • Resistant to micro-organisms
  • Resistant to root penetration
  • High dimensional stability due to glass fleece inlay
  • Compatible to bitumen
  • Resistant to permanent UV irradiation
  • Resistant against impact load and hail
  • Resistant to all common environmental influences
  • Resistant to mechanical influences
  • Hot air welding without use of open flame
  • Recyclable
Packaging

Sarnafil® TG 66-18 standard rolls are wrapped individually in a blue PE-foil.

Packing unitSee price list
Roll length15.00 m (49.2 ft)
Roll width2.00 m (6.56 ft)
Roll weight54.00 kg (119 lb)
Colour
SurfaceMatt
Colours
Top surfaceBeige Grey (nearest RAL 7040)
Bottom surfaceBlack
Typical Product Data
APPROVALS / CERTIFICATES

Sarnafil® TG 66-18 is designed and manufactured to meet most international recognised standards.
- Polymeric sheets for roof waterproofing according to EN 13956, certified by notified body 1213-CPD-3914 and provided with the CE-mark.
- Reaction to fire according to EN 13501-1.
- Official Quality Approvals and Agrement Certificates.
- Monitoring and assessment by approved laboratories.
- Root penetration resistance tested according to FLL-Test Procedure.

Shelf life

5 years from date of production in unopened, undamaged and original packaging.

Storage conditions

Rolls must be stored between +5 °C (+41 °F) and +30 °C (+86 °F) in a horizontal position on pallet, protected from direct sunlight, rain and snow. Do not stack pallets of rolls or any other material during transport or storage.

Product Declaration

EN 13956

Visible Defects

Pass (EN 1850-2)

Length

15 m (49.2 ft) (-0 % / +5 %) (EN 1848-2)

Width

2 m (6.56 ft) (-0.5 % / +1 %) (EN 1848-2)

Effective Thickness

1.8 mm (0.0709 in) (-5 % / +10 %) (EN 1849-2)

Straightness

≤ 30 mm (1.18 in) (EN 1848-2)

Flatness

≤ 10 mm (0.394 in) (EN 1848-2)

Mass per unit area

1.8 kg/m² (- 5 % / + 10 %) (EN 1849-2)

System Structure

Wide range of accessories is available e.g. prefabricated parts, roof drains, scuppers, protection sheets and separation layers.
The following accessories shall be used:
- Sarnafil® T 66-15 D Sheet for detailing
- Sarnafil® T Metal Sheet
- Sarnabar
- Sarnafil® T Welding Cord
- Sarnafil® T Prep
- Sarnacol® T 660
- Sarnafil® T Clean

Compatibility

Sarnafil® TG 66-18 may be installed on all thermal insulations and levelling layers suitable for roofing. No additional separation layer is required.
Sarnafil® TG 66-18 is suitable for installation directly on top of existing, carefully cleaned, level bituminous roofing, e.g. re-roofing over old flat roofs.
Colour changes in membrane surface may occur in case of direct contact with bitumen.

Resistance to Impact

Hard substrate ≥ 1000 mm (39.4 in)
Soft substrate ≥ 1250 mm (49.2 in)

Resistance to Static Load

Soft substrate ≥ 20 kg (44.1 lb)
Rigid substrate ≥ 20 kg (44.1 lb)

Resistance to Root Penetration

Pass (EN 13948)

Tensile Strength

Longitudinal (md) 1) ≥ 9 N/mm² (1305 psi)
Transversal (cmd) 2) ≥ 7 N/mm² (1015 psi)

Elongation

Longitudinal (md) 1) ≥ 550 %
Transversal (cmd) 2) ≥ 550 %

Dimensional Stability

Longitudinal (md) 1) ≤ 0.2 %
Transversal (cmd) 2) ≤ 0.1 %

Joint Shear Resistance

≥ 500 N / 50 mm (1.97 in) (EN 12317-2)

Foldability at Low Temperature

≤ -45 °C (113 °F) (EN 495-5)

Reaction to Fire

Class E (EN ISO 11925-2, classification to EN 13501-1)

Effect of Liquid Chemicals, Including Water

On request (EN 1847)

Exposure to Bitumen

Pass 3) (EN 1548)

Resistance to UV Exposure

Pass (> 5 000 h / grade 0) (EN 1297)

Watertightness

Pass (EN 1928)

Application
Ambient Air Temperature

-20 °C (68 °F) min. / +60 °C (+140 °F) max.

Substrate Temperature

-30 °C (86 °F) min. / +60 °C (+140 °F) max.

SUBSTRATE QUALITY

The substrate surface must be uniform, smooth and free of any sharp protrusions or burrs, etc.

The supporting layer must be compatible to the membrane, solvent resistant, clean, dry and free of grease and dust. Metal sheets must be degreased with Sarnafil® Cleaner before adhesive is applied.

APPLICATION

Installation works must be carried out only by Sika instructed contractors for roofing.

Installation of some ancillary products, e.g. contact adhesives / cleaners is limited to temperatures above +5 °C (+41 °F). Please observe information given by Product Data Sheets. Special measures may be compulsory for installation below +5 °C (+41 °F) ambient temperature due to safety requirements in accordance with national regulations.
