Sarnavap® 3000 M, Vapor Diffusion Control Layer

Sarnavap® 3000 M, Vapor Diffusion Control Layer

Waterproofing
SIKA

Sika is a global leader in specialty chemicals for the construction and industrial sectors. The company develops and supplies innovative products and systems for bonding, sealing, damping, reinforcing, and protecting structures. With a strong focus on sustainability and performance, Sika serves a wide range of applications including concrete production, waterproofing, roofing, flooring, and structural strengthening.

Read more
https://www.polytrade.global/web/image/product.template/40774/image_1920?unique=c88dc28

5,328.84 lei Tax Included
5328.84 RON

Not Available For Sale

You have already submitted a query for this product today.

This combination does not exist.

Contact Us
Preview TDS
Download TDS
General Specifications
Packaging Roll
Width 1.50 m (+ 0.3 m / - 0.0 m) mm
Length 50.00 m (+ 1.4 m / - 0.0 m) m
Weight 400 g/m² (± 40 g/m 2 ) Kg
Usage Vapour control layer for flat roofs
Chemical Base Low density polyethylene (PE-LD) with polyethylene foam layer
Usage Area -
Color Surface: smooth, PE-LD foil. Colors: Upper surface: black Lower surface: white polyethylene foam
Storage Conditions Rolls: +5…+30 °C, horizontal on pallet, away from sun/rain/snow
Density -
Consumption -

VAPOR DIFFUSION CONTROL LAYER

Sarnavap®-3000 M is a vapor diffusion control layer based on polyethylene (PE). The lower part is covered with a layer of polyethylene foam, and the longitudinal edge is provided with butyl tape.

Use
  • The vapor control layer (VCL) is applied over the most common types of backing layers. Substrates must be dry and strong enough to support foot traffic.
  • Sarnavap®-3000 M vapor control layer is used for flat roofs. The film is designed for slightly rough surfaces.
Advantages
  • It is easy and quick to assemble.
  • Remains flexible at low temperatures.
  • It does not deteriorate over time.
  • Permanent resistance to water vapor diffusion.
  • Recyclable.
pack

Rolls of Sarnavap®-3000 M are individually wrapped in PE foil.

Packaging unit:see price list
Roll length:50.00 m (164 ft)
Roll width:1.50 m (4.92 ft)
Roll weight:30.00 kg (66.1 lb)
Color
Surface:smooth, PE-LD foil.

Colors:

Upper surface:black
Lower surface:white polyethylene foam
Typical technical data
APPROVALS / CERTIFICATIONS

- CE marking according to the EN 13984 standard.
- Reaction to fire according to the EN 13501-1 standard.
- EN ISO 9001/14001 quality management system

Chemical base

Low density polyethylene (PE-LD) with polyethylene foam layer.

Validity period

5 years from the date of production and in accordance with the storage conditions in the original, unopened and undamaged packaging.

Storage conditions

The rolls must be stored between +5 °C (+41 °F) and +30 °C (+86 °F), in a horizontal position on the pallet, protected from direct sunlight, rain and snow. Do not stack roller pallets during transport or storage.

Product statement

EN 13984

Length

50.00 m (164 ft) (+ 1.4 m (+ 4.59 ft) / - 0.0 m (0 ft)) (EN 1848-2)

Width

1.50 m (4.92 ft) (+ 0.3 m (+ 0.984 ft) / - 0.0 m (0 ft)) (EN 1848-2)

Effective thickness

0.40 mm (0.0157 in) (± 0.04 mm (± 0.0016 in)) + foam 1.0 mm (0.0394 in) (+ 0.3 mm (+ 0.0118 in) / - 0.2 mm (0.0079 in)) (EN 1849-2)

Linearity

Hi (EN 1848-2)

Mass per unit area

400 g/m² (± 40 g/m 2 ) (EN 1849-2)

System structure

Auxiliary, complementary products:
- Sarnavap® Tape F.
- Sarnatape® 20 (for sealing against drafts in the attic area, porous substrates must first be treated with Primer 130).
- Primer 130.

Impact resistance

≥ 300 mm (11.8 in) (EN 12691 * )
* with h = 300 mm (11.8 in)

Tensile strength

longitudinal ≥ 160 N/50 mm (1.97 in)
transverse ≥ 130 N/50 mm (1.97 in)

Elongation

longitudinal ≥ 80%
transverse ≥ 55 %

Tear resistance

longitudinal ≥ 55 N
transverse ≥ 40 N

Reaction to fire

Class E (EN ISO 11925-2:2002) (classification according to EN 13501-1)

Alkalinity resistance

Hi (EN 13984 Annex C) (EN 12311-2)

UV resistance

Not applicable for permanent exposure to UV radiation.

Artificial aging

Good (EN 1296 / EN 1931)

Impermeability

Hello (EN 1928)

Application
Ambient air temperature

-20 °C (68 °F) min. / +60 °C (+140 °F) max.

Support temperature

-30 °C (86 °F) min. / +60 °C (+140 °F) max.

SUPPORT QUALITY

Substrates must be smooth, dry and strong enough to support foot traffic.

APPLICATION
  1. Unroll the roll of Sarnavap®-3000 M over the structural support layer and temporarily orient it into position.
  2. Roll out the next roll of Sarnavap®-3000 M placing it so that the overlaps between the strips are at least 80 mm (3.15 in).
  3. Peel off the protective strip of the adhesive tape and carefully fold the top sheet of Sarnavap®-3000 M making sure no creases form.
  4. Press the upper sheet of Sarnavap®-3000 M with a pressure roller to ensure a good adhesion with the Sarnavap® Tape F adhesive tape. When applying the sheet to the corrugated sheet, the overlap must be made on the upper fold of the sheet so that we can apply adequate pressure for optimal sealing of the overlaps.
  5. At transverse joints, sealing is achieved by cutting the edge of the upper sheet at 45°.
  6. In the perimeter and perforation areas, the Sarnavap®-3000 M film will rise on the vertical sides and stick with Sarnatape® 20 double-adhesive tape on the structure of the vertical element. Porous surfaces will first be treated with Primer 130.

Installation work must only be carried out by Sika authorized roofing membrane applicators.

Application of auxiliary products, e.g. the double-adhesive contact tape and the primer, is limited to temperatures above +5 °C (+41 °F). Please consult the technical data sheets of the respective products. For application at an ambient temperature below +5 °C (+41 °F), mandatory measures may be required due to safety requirements according to national regulations.

Note: Sarnavap®-3000 M is not recommended as a final waterproofing layer. This film is not designed as a roof membrane and therefore cannot replace the membrane for waterproofing.
