CANADIAN SOLAR, S1K5650A01 ( CSI-SolBank-S-2967-4h-US ), Energy Storage System (ESS)

BESS
CANADIAN SOLAR

Canadian Solar is one of the most bankable companies in the solar and renewable energy industry, having been publicly listed on the NASDAQ since 2006. Canadian Solar has two business segments: CSI Solar and Recurrent Energy

Read more
https://www.polytrade.global/web/image/product.template/10151/image_1920?unique=ab4a244
You have already submitted a query for this product today.

Această combinație nu există.

Contactați-ne
Preview TDS
Download TDS
Identification
Brand CANADIAN SOLAR
Cod producator S1K5650A01 ( CSI-SolBank-S-2967-4h-US )
General Specifications
Lățime 6058.0 mm
Înălțime 2438.0 mm
Adâncime 2896.0 mm
Greutate 29800.0 Kg
Temperatura de funcționare -30 >< 55 °C
Altitudine maximă de funcționare 2000.0 m
Umiditate relativă ≤95 %
Evaluare IP IP 55
Chimia bateriei Lithium Iron Phosphate (LFP)
Eficienţă Max. ≥ 94% %
Electrical Data
Putere nominală de ieșire AC N/A kVA
Putere DC nominală 700.0 kW
Capacitate de stocare 2800.0 kWh
Tensiune DC (nominală) 1324.8 V
Interval de tensiune DC 1159,2 ~ 1490,4 V
Max.Curent De Scurtcircuit 70.0 A
Protection
Protecţie <table class="table table-bordered"> <tbody> <tr> <td> <p style="text-align: justify;"> Thermal Management System: Liquid cooling/heating for battery system, air cooling for electrical components and humidity control. <br> Control Backup: 2-hrs UPS for control system including BMS, installed in the container. <br> Fire Detection and Alarm: Heat and smoke detection, alarm panel, bell and strobe with up to 24 hours UPS backup <br> Explosion Prevention: Gas detection with active ventilation. <br> Fire Suppression: Aerosol-based fire suppression system option available <br> Emergency Stop/Shut-off: Local and Remote. </p> <br> </td> </tr> </tbody> </table>
Communication
Interfață de comunicare Ethernet / RS485 / CAN
Protocolul de comunicare Modbus TCP / Modbus RTU / CAN 2.0

General Description & Application


SolBank Energy Storage System

Canadian Solar SolBank is a modular, flexible, and cost-effective MWh-scale battery energy storage system. Multiple SolBanks could be connected in parallel. This product is designed to meet energy storage needs for today and for the future.


Key Features

  • Cost-effective and long service life
  • 280Ah LFP cell leads to high energy density
  • Active balancing BMS on pack and rack level, releases more energy and extends the life of the system
  • Liquid cooling technology with cell temperatures being controlled within the optimal operating range
  • Battery pack IP65 seal grade, avoid dust, moisture,and water condensation
  • Multi-stage thermal spread technology, effectively prevents battery heat spread and improves safety
  • Multi-level fire detection, monitor early thermal runaway of cells
  • All internal components including battery packs assembled in factory, reducing on-site installation costs
