High strength grout with applied nanotechnology for grouting offshore wind turbine installations

SikaGrout^®-9800 is a shrinkage compensated, cement based grout which when mixed with water, produces a homogeneous, flowable and easy pump able grout with exceptional mechanical and physical properties. Latest best binder packing models and applied cementitious nanotechnology produces a grout with superior technical performance and exceptional rheological properties.

C90/105 concrete strength class according EN206 and DIN1045
Can be installed with a continuous mixing and pumping process. Typical output rates of ≥ 20 m³/hour per mixing unit.
Quick return to service and removal of temporary supports due to high early strength build-up. ≥ 40 MPa @ 24hrs at 20°C.
Very good strength gain at low temperatures.
No segregation or bleeding to ensure consistent physical performance inside the grouted connection, and to prevent pump blockages.
Excellent fatigue resistance
No wash-out during below water grouting.
Pump able over long distances and large heights.
Specially graded sands and exceptional flow and low friction increases pump output, reduces installation times and costs as well as reducing pump pressures and wear.
Available as silo material.

Usage

SikaGrout^®-9800 has been especially formulated for large scale, pump applications.

Grouting of grouted connections in offshore installations, e.g. foundations of wind turbines or oil & gas installations.
Typical applications are pile-sleeve and stab-in-pile grouted connections, clamp repair, leg filling etc…
Grouting under very harsh conditions, e.g. offshore applications or below water grouting, at temperatures as low as 2°C or up to 42°C.
All void filling from 30 mm to 600mm thickness where high strength is important.

Contact the Technical Department of your local Sika office regarding any application required not mentioned here.

Advantages

C90/105 concrete strength class according EN206 and DIN1045
Can be installed with a continuous mixing and pumping process. Typical output rates of ≥ 20 m³/hour per mixing unit.
Quick return to service and removal of temporary supports due to high early strength build-up. ≥ 40 MPa @ 24hrs at 20°C.
Very good strength gain at low temperatures.
No segregation or bleeding to ensure consistent physical performance inside the grouted connection, and to prevent pump blockages.
Excellent fatigue resistance
No wash-out during below water grouting.
Pump able over long distances and large heights.
Specially graded sands and exceptional flow and low friction increases pump output, reduces installation times and costs as well as reducing pump pressures and wear.
Available as silo material.

Packaging

SikaGrout^®-9800 is supplied by bulk transport and is stored in special jobsite silos. Upon request, the material may be available as well in special 1000, 1250 kg kg big bags.

Technical Information

Compressive Strength

Determined as part of DNV GL verification:

N/mm²	20 ^oC	2 ^oC
3 days	83.8	58.9
7 days	94.7	79.4
28 days	103.1	91.8
90 days	124.3	100.5

Characteristic compressive strengths (Determined as part of DNV verification):

N/mm2	20 ^oC	2 ^oC
28 days	94.5	88.4

Typical values - Additional test results

N/mm²	20 ^oC	5^oC	2^oC
3 days	≥ 75	≥ 45	≥ 40
7 days	≥ 85	≥ 70	≥ 65
28 days	≥ 95	≥ 80	≥ 75

Characteristic compressive strengths:

Specimen size	20 ^oC	5 ^oC
100 mm cubes	X_k(n)≥90 N/mm²	X_k(n)≥ 80 N/mm²
150 x 300 mm cylinders	X_k(n)≥90 N/mm²

Exposure classes

XO, XC4, XD3, XS2, XS3, XF3, XA2, WA

(EN 206-1, DIN
1045-2)

Modulus of Elasticity in Compression

GPa
Static	≥ 30
Dynamic	≥ 35

Determined as part of DNV GL verification:

	GPa
Static	34.9

Poisson ratio (Determined as part of DNV GL verification):

0.271

(ASTM C469)

Flexural Strength

Age	N/mm²
28 days	≥ 10

Characteristic flexural strength:

X_k(n) ≥ 9 N/mm²

(700 x 150 x 150
mm bars)

Determined as part of DNV GL verification:

N/mm²	20 ^oC	2 ^oC
28 days	13.6	12.7

N/mm²	20 ^oC	2 ^oC
28 days	13.6	12.7

Shrinkage

≤ 0.4 mm/m

(Schleibinger
shrinkage drain
method)

(test started 90 minutes after mixing – air sealed samples)

Shrinkage class:

SKVM 0

DAfStb VeBMR Rili)

Autogenous shrinkage (Determined as part of DNV GL verification):

-0.309 mm/m

(ASTM C1698)

(test started after initial set of the material)

Bleeding

No bleeding

Sedimentation stability:

No sedimentation

(in accordance of DAfStb Self compacting concrete, section N.1.2.)

Application Information

Layer Thickness

30 - 600 mm

Product Temperature

+2 °C min. / +42 °C max.

Ambient Air Temperature

+2 °C min. / +42 °C max.

Mixing Ratio

Approximately 145 lt / 1000 kg powder

Substrate Temperature

+2 °C min. / +42 °C max.

Pot Life

≥ 120 minutes

Setting time

≤ 10 hours

The above design is only a sample of the options available, for reference purposes only. Our policy of continuous improvement may result in a change of specifications without notice. If any discrepencies might be between the data sheet values and standards, we reserve the rights to make technical changes. Our company will not be held responsible, as all or any of pictures, drawings, weights and dimensions details or other elements in this document are only indicative and must not be considered contractual. Contact our sales team for other specifications or custom made products.

Contact our sales team for other specifications or custom made products.

Preview TDS

Download TDS

General Specifications
Packaging	1000 kg
Chemical Base	Shrinkage compensated cement
Usage	Large-scale pump applications for offshore installations and wind turbines
Usage Area	Exterior
Color	N/A
Working Time	N/A
Product Temperature	5 - 42 °C
Application Thickness	30 mm >< 600 mm
Ambient Air Temperature	+2 °C min. / +42 °C max.
Storage Conditions	Product must be stored in closed silos or warehouse under dry conditions.
Density	2.25 g/cm³
