Sarnafil® TS 77-18, FPO Double Reinforcement Membrane

Name: Sarnafil® TS 77-18, FPO Double Reinforcement Membrane
Brand: SIKA
SKU: PTG255.00142
Price: 6714.00 RON
Availability: InStock

Category: Waterproofing

SIKA

Sika is a global leader in specialty chemicals for the construction and industrial sectors. The company develops and supplies innovative products and systems for bonding, sealing, damping, reinforcing, and protecting structures. With a strong focus on sustainability and performance, Sika serves a wide range of applications including concrete production, waterproofing, roofing, flooring, and structural strengthening.

8,123.94 lei Tax Included
8123.94 RON

This combination does not exist.

Polymeric membrane for mechanically fastened roof waterproofing

Sarnafil® TS 77-18 (thickness 1.8 mm (0.0709 in)) is a polyester reinforced, multi-layer, synthetic roof waterproofing sheet based on premium-quality flexible polyolefins (FPO) containing ultraviolet light stabilizers, flame retardant and an inlay of glass non-woven according to EN 13956. Sarnafil® TS 77-18 is a hot air weldable roof membrane formulated for direct exposure and designed to use in all global climatic conditions. Sarnafil® TS 77-18 is produced with an inlay of glass non-woven for dimensional stability and a polyester reinforcement for high strength. Sarnafil® TS 77-18 is provided for mechanically fastened roofing systems. Sarnafil® TS 77-18 has no built-in stress at the time of production and has a fully encapsulated carrier. The dimensional stability of Sarnafil® TS 77-18 is best in class. Suitable for use in hot and tropical climatic conditions.

Usage

Waterproofing membrane for:

Mechanically fastened roofing systems.
Enhancement of solar reflection of existing TPO roofs (relevant only for colour RAL 9016 SR).

Advantages

Proven performance over decades.
Various colours available.
High reflectance properties for cool roofing characteristics (relevant only for colour RAL 9016 SR).
Resistant to permanent UV irradiation.
High dimensional stability due to glass fleece inlay.
Resistant to permanent wind exposure.
Resistant against impact load and hail.
Resistant to all common environmental influences.
Resistant to micro-organisms.
Resistant to root penetration.
Compatible to old bitumen.
Hot air welding without use of open flames.
Recyclable.

Packaging

Sarnafil® TS 77-18 standard rolls are wrapped individually in a blue PE-foil.

Packing unit	See price list
Roll length	15.00 m (49.2 ft)
Roll width	2.00 m (6.56 ft)
Roll weight	59.50 kg (131 lb)

Colour

Surface
Standard	Matt
Solar refective	Glossy

Colours
Top surface	Beige Window grey (nearest RAL 7040) Anthracite (nearest RAL 7016) Copper brown (nearest RAL 8004) Reseda green (nearest RAL 6011) Traffic white (nearest RAL 9016) Traffic white, solar reflective (RAL 9016 SR)
Bottom surface	Black

Typical Product Data

APPROVALS / CERTIFICATES		Sarnafil® TS 77-18 is designed and manufactured to meet the most international recognised standards. - Polymeric sheets for roof waterproofing according to EN 13956, certified by notified body 1213-CPD-3915 and provided with the CE-mark. - Reaction to fire according to EN 13501-1. - External fire performance tested according to ENV 1187 and classified according to EN 13501-5: BROOF(t1). - Factory Mutual (FM) Approvals Class: 4470. - Official Quality Approvals and Agreement Certificates. - Monitoring and assessment by approved laboratories.
Shelf life		5 years from date of production in unopened, undamaged and original packaging.
Storage conditions		Rolls must be stored between +5 °C (+41 °F) and +30 °C (+86 °F) in a horizontal position on pallet, protected from direct sunlight, rain and snow. Do not stack pallets of rolls or any other material during transport or storage.
Product Declaration		EN 13956
Visible Defects		Pass (EN 1850-2)
Length		15 m (49.2 ft) (-0 % / +5 %) (EN 1848-2)
Width		2 m (6.56 ft) (-0.5 % / +1 %) (EN 1848-2)
Effective Thickness		1.8 mm (0.0709 in) (-5 % / +10 %) (EN 1849-2)
Straightness		≤ 30 mm (1.18 in) (EN 1848-2)
Flatness		≤ 10 mm (0.394 in) (EN 1848-2)
Mass per unit area		1.98 kg/m² (-5 % / +10 %) (EN 1849-2)
System Structure		Wide range of accessories is available e.g. prefabricated parts, roof drains, scuppers and walkway pads. The following accessories shall be used: - Sarnafil® T 66-15 D Sheet for detailing - Sarnafil® TS 77 Strips - Sarnafil® T Metal Sheet - Sarnabar® / Sarnafast® - Sarnafil® T Welding Cord - Sarnafil® T Prep - Sarnacol® T 660 - Sarnafil® T Clean
Compatibility		Sarnafil® TS 77-18 may be installed on all thermal insulations and levelling layers suitable for roofing. No additional separation layer is required. Sarnafil® TS 77-18 is suitable for installation directly on top of existing, carefully cleaned, levelled bituminous roofing, example re-roofing over old flat roofs. Colour changes in membrane surface may occur in case of direct contact with bitumen.
Resistance to Impact		Hard substrate ≥ 1000 mm (39.4 in) Soft substrate ≥ 1250 mm (49.2 in)
Hail Resistance		Rigid substrate ≥ 27 m/s Flexible substrate ≥ 35 m/s
Resistance to Static Load		Soft substrate ≥ 20 kg (44.1 lb) Rigid substrate ≥ 20 kg (44.1 lb)
Tensile Strength		Longitudinal (md) 1) ≥ 1000 N/50mm (1.97 in) Transversal (cmd) 2) ≥ 900 N/50mm (1.97 in) 1) md = machine direction 2) cmd = cross machine direction
Elongation		Longitudinal (md) 1) ≥ 13 % ≥ 13 % ≥ 13 % Transversal (cmd) 2) ≥ 13 % ≥ 13 % ≥ 13 % 1) md = machine direction 2) cmd = cross machine direction
Dimensional Stability		Longitudinal (md) 1) ≤ 0.2 % Transversal (cmd) 2) ≤ 0.1 % 1) md = machine direction 2) cmd = cross machine direction
Tear Strength		Longitudinal (md) 1) ≥ 300 N Transversal (cmd) 2) ≥ 300 N 1) md = machine direction 2) cmd = cross machine direction
Joint Peel Resistance		No failure in seam (EN 12316-2)
Joint Shear Resistance		≥ 500 N/50 mm (1.97 in) (EN 12317-2)
Foldability at Low Temperature		≤ -40 °C (104 °F) (EN 495-5)
External Fire Performance		B ROOF (t1) < 20° (EN 13501-5)
Reaction to Fire		Class E (EN ISO 11925-2, classification to EN 13501-1)
Effect of Liquid Chemicals, Including Water		On request (EN 1847)
Exposure to Bitumen		Pass 3) (EN 1548)
Resistance to UV Exposure		Pass (> 5000 h / grade 0) (EN 1297)
Watertightness		Pass (EN 1928)
Solar Reflectance Index		Colour Initial 3 years aged Test Institute RAL 9016 SR 109 94 CRRC CRRC tested products are listed in Cool Roof Rating Council (CRRC) product data base.
USGBC LEED Rating		Colour Initial 3 years aged RAL 9016 SRI > 82 SRI > 64 RAL 9016 SR SRI > 82 SRI > 64 Conform on the minimum requirements of LEED V4 SS credit 5 option 1 Heat Island reduction - Roof.

Application

Ambient Air Temperature

-20 °C (68 °F) min. / +60 °C (+140 °F) max.

Substrate Temperature

-30 °C (86 °F) min. / +60 °C (+140 °F) max.

SUBSTRATE QUALITY

The substrate surface must be uniform, smooth and free of any sharp protrusions or burrs, etc.

The supporting layer must be compatible to the membrane, solvent resistant, clean, dry and free of grease and dust. Metal sheets must be degreased with Solvent T 660 before adhesive is applied.

APPLICATION

Installation works to be carried out only by Sika instructed contractors for roofing.

Installation of some ancillary products, example contact adhesives / cleaners is limited to temperatures above +5 °C (+41 °F). Please observe information given by Product Data Sheets.

The above design is only a sample of the options available, for reference purposes only. Our policy of continuous improvement may result in a change of specifications without notice. If any discrepencies might be between the data sheet values and standards, we reserve the rights to make technical changes. Our company will not be held responsible, as all or any of pictures, drawings, weights and dimensions details or other elements in this document are only indicative and must not be considered contractual. Contact our sales team for other specifications or custom made products.

Preview TDS

Download TDS

General Specifications
Packaging	Roll
Width	2 m (-0.5 % / +1 %) mm
Length	15 m (-0 % / +5 %) m
Weight	1.98 kg/m² (-5 % / +10 %) Kg
Usage	Mechanically fastened roofs; solar-reflective TPO upgrade (RAL 9016 SR)
Chemical Base	-
Usage Area	-
Color	Matt/solar-reflective; 7 top colours (RAL); black underside
Storage Conditions	Rolls: +5…+30 °C, horizontal on pallet, away from sun/rain/snow
Density	-
Consumption	-
